LED TUBE LIGHT T8 TYPE |
| |
| |
 |
Product Appearance |
|
| |
LED Tube Series products provide the ideal direct replacement for existing T8 fluorescent tube fixtures in a wide variety of commercial environments, including: Hospitals, Schools, Offices, Shopping malls, Supermarkets,Museums, Computer rooms, Banks, Subway stations, Exhibition halls, Hotels, Underground parking garages etc. |
| |
|
| |
Features |
|
| |
• High brightness LED
• Light viewing angle over 120°
• Easy installation and low maintenance fee
• Green product. Free of mercury and hazardous materials
• Can be directly placed in conventional T8 fluorescent brackets after removing the ballast and starter
• Consumes reduced up to 55%, savings of up to 55% in electricity costs
• Reduced installation, maintenance, and replacement costs
• No UV or infrared radiation
• Long life span of up to 50,000 hours |
| |
|
|
| Specification |
| |
| Model |
BES-2S-10W（FR) |
BES-4S-16W(FR) |
BES-4H-20W(FR) |
BES-4H-20W(FR) |
| Length |
2 foot |
4 foot |
4 foot |
4 foot |
| Size |
Taiwan & Japan (J model) |
| 580mm x Ф26mm |
1,198 mm (L) x Ф 26 mm |
| Other Area |
| 588mm x Ф26mm |
1,199 mm (L) x Ф 26 mm |
| Rotatable End-cap |
available |
available |
available |
available |
| Power Consumption |
8W ± 1W |
16W ± 1W |
20W ± 1W |
20W ± 1W |
| Luminous Flux |
880lm |
1,760lm |
2,200lm |
2,400Lm |
| LED chip type and Q'ty |
Epistar 2,835*66pcs |
Epistar 2,835*120pcs |
Epistar 2,835*156pcs |
Epistar 2,835*297pcs |
| Color Temperature |
3,000K/4,000K/5,700K/6,500K |
| Equivalent to Fluorescent Tube |
20W |
40 W |
| Input Voltage |
AC100V ~ 240V |
| Lifetime |
> 50,000H |
| Global Certification |
UL,CE,ROHS |
| Warranty |
3 Y |
| Work condition |
Temperature |
-25~45℃ |
| Humidity |
Below 85% |
| * Do not use at high humidity or wet place. * |
|
| |
|
|
|
|
| |
LED TUBE LIGHT T8 SENSOR TYPE |
| |
|
|
Product Appearance |
|
| |
LED Tube Series products provide the ideal direct replacement for existing T8 fluorescent tube fixtures in a wide variety of commercial environments, including: Hospitals, Schools, Offices, Shopping malls, Supermarkets,Museums, Computer rooms, Banks, Subway stations, Exhibition halls, Hotels, Underground parking garages etc. |
| |
|
| |
Features |
|
| |
• Built-in microwave sensor
• High brightness LED
• Light viewing angle over 120°
• Easy installation and low maintenance fee
• Green product. Free of mercury and hazardous materials
• Can be directly placed in conventional T8 fluorescent brackets after removing the ballast and starter
• Consumes reduced up to 55%, savings of up to 55% in electricity costs
• Reduced installation, maintenance, and replacement costs
• No UV or infrared radiation
• Long life span of up to 50,000 hours |
| |
  |
| |
|
|
| Specification |
| |
| Model |
BES-4S-20SN |
| Size |
4 foot |
| Ф26mm*1198MM |
| Material |
Aluminum and Polycarbonate |
| Luminous Flux (Frosted pc cover) / (Clear pc cover) |
20％時＞340lm, 起動時＞1700lm |
| Color Temperature |
3000-3500K / 6000-6500K |
| Power Consumption |
9W(50%) / 18W(100%) |
| Equivalent to Fluorescent Tube |
40W |
| Input Voltage |
AC85-265V |
| Lifetime |
> 50,000 H |
| Global Certification |
CE / ROHS |
| Warranty |
2 Y |
| Work condition |
Temperature |
-30°C ~50°C |
| Humidity |
10% ~90%. |
| |
* Do not use at high humidity or wet place. * |
|
| |
|
|
|
|
| |
|
| |
|
|
Product Appearance |
|
| |
OKMR LED T5 Type can idrectly replace traditional existing T5 fluorescent lamps in a wide variety of commercial Environments, including:
Hospitals, Schools, Offices, Shopping malls, Supermarkets,
Museums, Computer rooms, Banks, Subway stations,
Exhibition halls, Hotels, Underground parking garages etc. |
| |
|
| |
Features |
|
|
．Internal driver
．Light viewing angle over 300°
．Easy installation and low maintenance fee
．Green product. Free of mercury and hazardous materials
．Can be directly placed in conventional T5 fluorescent brackets
after removing the ballast and starter
．Reduced installation, maintenance, and replacement costs
．No UV or infrared radiation
．Long life span of up to 50,000 hours |
| Specification |
| |
| Model |
FY-T5-16W |
| Size |
4 foot4 foot, G5 socket
|
| Ф24mm*1165mm |
| Material |
Aluminum and Polycarbonate |
| Luminous Flux (Frosted pc cover) |
>2000lm |
| Color Temperature |
3000-3500K / 6000-6500K |
| Power Consumption |
16W |
| Equivalent to Fluorescent Tube |
28W |
| Input Voltage |
AC85-265V |
| Lifetime |
> 50,000 H |
| THD |
<15% no+flicker driver |
| Warranty |
3 Y |
| Work condition |
Temperature |
-30°C ~50°C |
| Humidity |
10% ~90%. |
| |
* Do not use at high humidity or wet place. * |
|
| |
|
|
|
|
|
|
